Industrial Food Factory Sludge Dewatering in Malaysia



1. Project Overview

• Location: Selangor, Malaysia

• Industry: Food & Beverage Processing (Frozen Foods / Palm Oil / Snacks)

• Wastewater Type: High-grease and organic sludge

• Equipment: KOPAY-302 Multi-Disc Screw Press

2. The Challenge

The client in Malaysia was using a traditional centrifuge system, but faced several operational hurdles:

• High Oil Content: The food processing sludge contained high levels of fats, oils, and grease (FOG), making it difficult for many machines to separate water efficiently.

• Noise and Vibration: The old centrifuge was extremely noisy and required heavy foundation reinforcement.

• Maintenance Cost: Frequent breakdowns and expensive spare parts from European brands were hurting the factory’s ROI.

• Environmental Compliance: The moisture content of the sludge cake was too high, leading to high disposal fees from local waste contractors.

3. KOPAY’s Solution

KOPAY engineered a customized Sludge Dewatering Solution specifically for the Malaysian food industry:

• Anti-Clogging Rings: Our screw press uses moving and fixed rings to handle oily sludge without the need for high-pressure backwashing, saving thousands of gallons of water daily.

• Low-Speed Reliability: Operating at only 2-3 RPM, the KOPAY machine produces zero vibration and minimal noise, suitable for factories near residential areas.

• Plug-and-Play Design: We provided a skid-mounted system including the Polymer Dosing Unit, allowing for fast installation and immediate operation.

• SUS304 Construction: High corrosion resistance to withstand the acidic nature of food wastewater.

4. The Result

• Sludge Volume Reduction: The sludge cake moisture was successfully reduced to below 75%, significantly lowering disposal costs.

• Energy Efficiency: Power consumption was reduced by 60% compared to the previous centrifuge system.

• Fully Automatic: The system now runs 12 hours a day with zero manual supervision required, freeing up local staff for other tasks.

• DOE Approved: The treated effluent quality helps the plant maintain strict compliance with Malaysia’s Environmental Quality Act.



Need a solution for your food factory? [View our Multi-Disc Screw Press] or Get a Direct chat with our technical experts via WhatsApp.

And you can also Check out our successful project in a Malaysian food factory here!

Model (KOPAY)	Sludge Throughput (m³/h)	Dry Solids Capacity (kg-DS/h)	Power (kW)	Dimensions (LxWxH mm)
KOPAY-131	0.5 - 1.5(m³/h)	10 - 25(kg-DS/h)	0.55 kW	1950x750x1250mm
KOPAY-201	1.5 - 3.5(m³/h)	25 - 50(kg-DS/h)	0.75 kW	2450x950x1450mm
KOPAY-301	3.5 - 7.0(m³/h)	50 - 100(kg-DS/h)	1.10 kW	3150x1150x1650mm
KOPAY-401	8.0 - 15.0(m³/h)	120 - 240(kg-DS/h)	2.20 kW	4250x1450x1950mm
